Low Current 12 / 24 Volt Xtreme High Intensity LED Light Bar


12" LED Light Bar puts out the equivalent of 300 Watts Halogen and only draws 3 amps.

Introducing a first in 12v or 24v dc LED lighting technology with the Xmitter LED Light Bar. Designed for On and Off Road use, each weatherproof low profile light bar produces tremendous light output, with a 12" bar producing 3600 lumens, 100 more lumens than a 35 watt HID light, while drawing only 4 amps and boasting an astonishing 292,000 hour life span.

Low Current 12 / 24 Volt Xtreme High Intensity LED Bar

Each light bar is manufactured of stainless steel and aluminum for high strength and durability, but measuring in at less than 3" tall and 4" deep, Xmitter Light Bars are perfect for mounting in tight spaces where traditional lights would never fit. Xmitter Light Bars are available from 4" to 42" lengths and come standard with flat surface and tube mounts and rubber shock isolators. Each mount slides along the lower extrusion to match any existing mounting holes and it allows for horizontal and vertical adjustment, this patent pending technology is nonexistent with any other light! Tubing/roll cage mounts are also available in 1.5", 1.75" and 2" black anodized billet aluminum, sold separately.

The LED Xmitter bar is ideal for Dirt Bikers, snowmobilers, ATV and other people looking for a light source for their low power ride. The bar will automatically adjust itself to lower amperage so it can even run off a stator on a dirt bike. Available in Euro Beam (Long Distance) or Flood (Wide) Beams. Patent Pending

Model Length # of LEDs Watts Amp Draw Lumens Price
XIL-40 4" 4 12 1 720 $ 159.00
XIL-80 6" 8 24 2 1440 $ 279.00
XIL-120 8" 12 36 3 2160 $ 306.00
XIL-200 12" 20 60 5 3600 $ 499.00
XIL-400 22" 40 120 10 7200 $ 899.00
XIL-600 32" 60 180 15 10800 $ 1299.00
XIL-800 42" 80 240 20 14400 $ 1669.00
XIL-1000 52" 100 300 25 18000 $ 1899.00


XTREME INTENSITY LED Lamp Models

  • XIL-40: 4" 4 LED XMITTER LIGHT BAR, BLACK
  • XIL-80: 6" 8 LED XMITTER LIGHT BAR, BLACK
  • XIL-120: 8" 12 LED XMITTER LIGHT BAR, BLACK
  • XIL-200: 12" 20 LED XMITTER LIGHT BAR, BLACK
  • XIL-400: 22" 40 LED XMITTER LIGHT BAR, BLACK
  • XIL-600: 32" 60 LED XMITTER LIGHT BAR, BLACK
  • XIL-800: 42" 80 LED XMITTER LIGHT BAR, BLACK
  • XIL-1000: 52" 100 LED XMITTER LIGHT BAR, BLACK
  • Features
      Low Amp Draw
      Instant Light Output
      200,000 Hour Life
      Small Housing
      Efficient Heat Dissipation
      Mounting System within the extrusion
      Aluminum Housing


    Height 3.1"
    Total Length Varies by Model from 4" to 52"
    Depth 3.5"
    Housing Aluminum
    Number of LEDs Varies by model from 4 LED's to 100 LED's
    Bulb Type 3watt LEDs


    Low Current 12 / 24 Volt Xtreme High Intensity LED Light Bar Low Current 12 / 24 Volt Xtreme High Intensity LED Light Bar




    Availability: Usually ships in 2-3 business days.

    Low Current 12 / 24 Volt Xtreme High Intensity LED Light Bar
    Xtreme-LED-Light-BarRetail: $289.00Sale Price: $159.95 (You save: 45%)

    Voltage:
    Bar:
    Beam:  Qty:
